Special Embroidery Machine Series
Taping/Coiling embroidery machine
Flat, sequin, taping and cording — combined on one machine.
- Heads
- 4 – 20
- Needles
- 6 / 9 / 12
- Head interval
- 550 – 700 mm
MC904-600It integrates many embroidery methods such as flat embroidery, sequin and cording, thus making embroidery methods flexible and variable. Integrated with functions of flat, coiling, cording, flat tape, bead and sequin embroidery, making it ideal for high-end embroidery applications on fashion, wedding dresses, children's wear, home textiles, and other fields.
What the Taping/Coiling is built with.
- Optional head structures: Dual-Cam Dual Drive / Double Crank.
- High-precision gantry-milled monolithic frame structure.
- Industrial-grade high-performance computerized embroidery control system; 17-inch screen optional.
- Optional high-precision floating embroidery frame or C-frame.
- Servo motor drive, main drive with high-strength imported timing belts.
- High-precision custom gear transmission box.
- Optional head jump systems: stepping motor jump or solenoid jump.
- Interchangeable components enable embroidery on coils and tapes of various specifications.
- Taping/Coiling embroidery head options: 2.4x/3x capacity winding reels with robotic multi-color tape/coil changing.
- Optional trimming systems: High-efficiency stepper motor static cutter / Lead screw cutter / AC servo cutter.
- Optional accessories based on head interval: Sequin, easy-cording, bead, laser cutting and boring devices; with automatic functions such as automatic tape/coil cutting.
- Multiple embroidery effects including coiling, flat tape, cording, feather-stitch and zigzag can be achieved through accessory selection and computerized parameter adjustment.
Models and specifications
All 8 configurations listed in the official catalogue. Scroll sideways on a phone to see every column.
General machine specifications
| Model | Needles | Heads | Head interval (mm) | Embroidery area (mm) | Inner frame size (mm) | Machine size (mm) |
|---|---|---|---|---|---|---|
| MC904 | 9 | 4 | 600 | 700*900 | 3040*940 | 5070*2357 |
| MC904 | 9 | 4 | 700 | 800*1000 | 3440*1040 | 5570*2557 |
| MC906 | 9 | 6 | 600 | 1200*1500 | 4740*1640 | 7210*3757 |
| MC612 | 6 | 12 | 600 | 700*1000 | 7740*1040 | 9720*2557 |
| MC912 | 9 | 12 | 600 | 700*1000 | 7840*1040 | 9870*2557 |
| MC1215 | 12 | 15 | 660 | 1000*1500 | 10920*1710 | 13380*3757 |
| MC918 | 9 | 18 | 600 | 620*1000 | 11360*1140 | 13350*2757 |
| MC920 | 9 | 20 | 550 | 600*1000 | 11590*1040 | 13290*2577 |
Specifications and descriptions on this page are taken from the official Sinsim full-range catalogue 2025 (pages 25–26). Dimensions are in millimetres as printed. Sinsim builds to order, so confirm the final configuration with us before purchase.
What it produces.
Built with brands the industry trusts.
Sinsim builds with internationally recognised component brands, as featured in its official catalogue. Optional sequin, bead, cording, laser and boring devices are described on our devices page.
- Groz-Beckert
- Schmetz
- Organ
- Hirose
- Dotec
- Koban
- Desheng
- Kobest
